Fig. S4

ID
ZDB-IMAGE-120918-5
Source
Figures for Sorrells et al., 2012
Figure Caption

Fig. S4 Loss of ccdc94 compromises the anti-apoptotic function of Bcl-2. Wild-type (wt, derived from crossing wild-type parents) or rs7 mutant embryos (derived from crossing rs7 heterozygous parents) were injected at the one-cell stage of development with the indicated amounts of mRNA encoding zbcl-2, zbcl-xL, or egfp as a control (cntl). Embryos were then irradiated at 24 hpf with 8 Gy IR and analyzed three hours later by immunofluorescence to detect activated Caspase-3. Mutants were genotyped as in Figure 2C–2D. Representative data from three independent experiments is shown.
