Figure Caption
Fig. 7 ISKNV ORF111L and zebrafish TRAF2 overexpression resulted in caspase 8 and caspase 3 upregulation.
(A–B) The caspase 8 or caspase 3 expression was shown in wild type embryos by whole mount RNA in situ hybridization assay. (C–D) ISKNV ORF111L overexpression resulted in significant caspase 8 (C, arrow) and caspase 3 (D, arrow head) upregulation. (E–F) Zebrafish TRAF2 overexpression induced modest caspase 8 (E, arrow) and caspase 3 (F, arrow head) upregulation compared with those of ORF111L. All embryos shown represent the typical staining and are lateral views with anterior to the left at 3 dpf.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ PLoS One
