ZFIN Image: Simmons et al., 2012, Fig. 6


Figure Caption

Fig. 6

Loss of pes^vu166 function results in nonautonomous defects in oligodendrocyte morphology and axogenesis.

(A–G) Lateral views of spinal cords in 3 dpf larvae. Expression from Tg(nkx2.2a:mGFP) reporter marks oligodendrocytes and axons. (A) Oligodendrocyte with normal axon wrapping morphology (arrows) in wild-type larva. (B) Oligodendrocyte with disorganized membrane morphology (arrowhead) and no evidence of axon wrapping in pes^{vu166 -/-} larva. (C) Genetically wild-type oligodendrocyte transplanted into a pes^{vu166 -/-} larva had abnormal membrane extensions and no axon wrapping. (D) Genetically mutant oligodendrocyte transplanted into a wild-type larva wrapped axons normally. (E) Axon in wild-type larva. (F) Axon in pes^{vu166 -/-} larva showing wandering trajectory, abnormal forking and growth cone collapse (asterisks *). (G) Genetically mutant axon transplanted into a wild-type larva had normal trajectory and morphology. (H,I) Transverse sections through the spinal cord of 3 dpf wild-type (H) and pes^{vu166 -/-} (I) larvae showing Zrf-1⁺ radial glia.

Figure Data

Expression / Labeling details

Phenotype details
