Fig. 5

Co-injection of suboptimal ccm3a/b (0.25 ng) and stk25b (3 ng) MO results in cranial vasculature defects at 54 hpf. Embryos injected with low doses of ccm3a/b (0.25 ng) or stk25b morpholino (3 ng) showed no obvious defects in their cranial vessels (A-D). Co-injection of both morpholinos at the same dosages resulted in gross dilation of the prosencephalic arteries (PrA), anterior cerebral veins (AceV), as well as enlargement and mispatterning of the mesencephalic veins (MsV) in 71% of the embryos (E–H, yellow arrows, n = 83).
