ZFIN ID: ZDB-IMAGE-110816-16
Figures for Takano et al., 2010


Figure Caption/Comments:

Fig. 3 Expression pattern of sbno1 during zebrafish embryogenesis detected by whole-mount in situ hybridization. A: A lateral view of early cleavage stage (2 hours postfertilization [hpf]) embryo. B: A lateral view of 50% epiboly stage (5 hpf) embryo. C,D: A 90% epiboly stage (9 hpf) embryo. E,F: A bud stage (10 hpf) embryo. G,H: A 3-somite stage (11 hpf) embryo. I: A 10-somite stage (15 hpf) embryo. J,K: A 18-somite (18 hpf) stage embryo. C,E,G,J are views from animal pole of the in situ specimen. In D,F,H,I,K, lateral views of in situ specimen is shown with ventral to the left.

Figure Data:
