Figure Caption
Fig. S5
Expression of foxa1/2/3 and gata4/6 appears unaffected in embryos that overexpress caFgfr1. Embryos obtained from outcrossing Tg(hsp70l:XlFgfr1) zebrafish were heat-shocked at 26 hpf, and harvested at 38 hpf for in situ hybridization. (A-J) The expression of foxa1 (A,B), foxa2 (C,D), foxa3 (E,F), gata4 (G,H) and gata6 (I,J), which encode factors implicated in hepatic competence, appears unaffected in embryos that overexpress caFgfr1 compared with controls (100%, n=10-12). Arrows indicate the liver. Dorsal views, anterior towards the left. Scale bar: 100 μm.
