ZFIN Image: Wilkinson et al., 2009, Fig. S5


Figure Caption

Fig. S5 Heat Shock Induced Expression of tBR Leads to a Loss of runx1 Expression Within the DA Without Affecting Neural runx1 Expression.

a-h) Expression of runx1 within the DA (red arrowheads), olfactory placode (blue arrowheads) Rohon-Beard sensory neurons (yellow arrowheads) and otic vesicle (black arrowheads) in embryos heatshocked at 21hpf. Whereas runx1 is expressed in the dorsal aorta, olfactory placode, otic vesicle and Rohon-Beard sensory neurons at 23hpf and 24hpf in control GFP- embryos (black letters), it is specifically lost from the dorsal aorta in GFP+ embryos (green embryos), whilst retaining its neural expression.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Cell, 16(6), Wilkinson, R.N., Pouget, C., Gering, M., Russell, A.J., Davies, S.G., Kimelman, D., and Patient, R., Hedgehog and Bmp polarize hematopoietic stem cell emergence in the zebrafish dorsal aorta, 909-916, Copyright (2009) with permission from Elsevier. Full text @ Dev. Cell
