Figure Caption
Fig. S9 Additional wild-type to uhrf1 transplants. Donors were wild-type siblings. (A,C,E,G) Whole mount and histology images of non-mosaic eye of host embryo. (B,D,F,H) Whole mount and histology images of mosaic lens. The percent mosaic lens composition of donor cells is indicated on each whole-mount image. Mosaic lenses were scored as (D,F,H) normal (no phenotype), or (B) mild. Scale bars are 80 μm.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 350(1), Tittle, R.K., Sze, R., Ng, A., Nuckels, R.J., Swartz, M.E., Anderson, R.M., Bosch, J., Stainier, D.Y., Eberhart, J.K., and Gross, J.M., Uhrf1 and Dnmt1 are required for development and maintenance of the zebrafish lens, 50-63, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
