Figure Caption
Fig. S4 Whole-mount in situ hybridization of the mesodermal marker no tail (ntl) in git2a morphants. Lateral (A) and dorsal (B) views of embryos showing expression of the mesodermal marker no tail (ntl) in control and git2a morphant embryos at comparable stages of epiboly.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 349(2), Yu, J.A., Foley, F.C., Amack, J.D., and Turner, C.E., The Cell Adhesion-associated Protein Git2 Regulates Morphogenetic Movements during Zebrafish Embryonic Development, 225-237, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
