ZFIN Image: Yasuda et al., 2010, Fig. 3


Figure Caption

Fig. 3 Localization of cyclin B1 and reporter mRNAs during oogenesis. (A?H) Section in situ hybridization using cyclin B1 (A, E) and gfp (B?D, F?H) probes of stage III (A?D) and stage IV (E?H) oocytes derived from wild-type (A, E) and transgenic fish carrying tgo3′ (B, F), tg3′ (C, G) or tgs (D, H) gene. Arrows indicate the micro-pile existing at the animal pole of fish oocytes. cyclin B1 and tgo3′ mRNAs were localized in the cortical cytoplasm beneath the animal pole of stage III (A, B) and IV (E, F) oocytes. tg3′ mRNA was localized to the animal pole of stage III oocytes (C) but disappeared in stage IV oocytes (G). tgs mRNA showed no localization during oogenesis (D, H). GV, germinal vesicle. Bars indicate 100 μm.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 348(1), Yasuda, K., Kotani, T., Ota, R., and Yamashita, M., Transgenic zebrafish reveals novel mechanisms of translational control of cyclin B1 mRNA in oocytes, 76-86, Copyright (2010) with permission from Elsevier. Full text @ Dev. Biol.
