ZFIN Image: März et al., 2010, Fig. 6


Figure Caption

Fig. 6 A fraction of the proliferating cells in the RMS are Tg(olig2:EGFP) positive. A–C: The majority of Tg(olig2:EGFP)-positive cells (A) in the anterior part of the RMS co-express PCNA (arrow in A–C). However, only the medial part of the anterior RMS stripe expresses Tg(olig2:EGFP). Arrowheads in C indicate PCNA-only-expressing cells located dorsal and ventral to the Tg(olig2:EGFP)-positive cluster. D–F: A part of the Tg(olig2:EGFP)-positive cells (D) in the RMS of the medial telencephalon co-express PCNA (arrow in D–F). Arrowhead in E and F indicates PCNA-only-expressing cells located dorsal to the Tg(olig2:EGFP)-positive cluster. Note that expression of Tg(olig2:EGFP) is observed also ventral to the RMS (asterisk) (see also Fig. 5E, G). Scale bar = 25 μm.
