Figure Caption
Fig. 3 Endocytosis in zebrafish larvae treated with novel lipid absorption inhibitors.
(A?H) Histological cross-sections through the anterior intestine of control and compound treated larvae following ingestion of AM1-43. AM1-43 uptake is inhibited in larvae treated with compounds 2, 7 and A10 whereas it is only slightly diminished in larvae treated with compounds 10, B10 and B11. Cell nuclei (blue) stained with Dapi. All compounds used at 25 μM.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ PLoS One
