Fig. S1

ID: ZDB-IMAGE-100806-168
Publication: Herrgen et al., 2010 - Intercellular Coupling Regulates the Period of the Segmentation Clock
All Figures: Figures for Herrgen et al., 2010


Figure Caption

Fig. S1 Expression of mesoderm and ectoderm differentiation markers in mib embryos
In situ hybridization with ectoderm (A) and mesoderm (B, C) markers in the PSM of wildtype/heterozygous and mib embryos at the 10 somite stage. Elevated expression of isl1 in (B) in interneurons and Rohon-Beard neurons (n, out of focal plane) and reduced expression of mespa (arrow in C) is observed in mib embryos, either of which was used to distinguish wildtype/heterozygous from mib embryos. Dorsal view with anterior to the top. Expression patterns were assessed in at least five embryos per experimental condition. Scale bars = 25 μm.
