ZFIN Image: Branam et al., 2010, Fig. S1


Figure Caption

Fig. S1 Chd can rescue embryos ventralized by co-injection of Chl- and Chd-MOs. (A) Embryos were dorsalized by injection of RNA (80 pg) encoding Chd. Also shown, for comparison, is a representative embryo injected with 0.38 mM StCon-MO. Embryos co-injected with Chd-MO (.026 mM) and Chl-MO (0.1mM) are moderately to severely ventralized, whereas overexpression of Chd RNA (80 pg) rescues embryos co-injected with Chd-MO and Chl 5′1, such that many are only mildly ventralized or mildly (left bottom panel) or strongly dorsalized (right bottom panel). (B) Quantification is shown of phenotypes at 24 hpf. Co-injection with p53-MO was to control for the possibility of off-target effects.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 341(2), Branam, A.M., Hoffman, G.G., Pelegri, F., and Greenspan, D.S., Zebrafish Chordin-like and Chordin Are Functionally Redundant in Regulating Patterning of the Dorsoventral Axis, 444-458, Copyright (2010) with permission from Elsevier. Full text @ Dev. Biol.
