Fig. S4

ID

ZDB-IMAGE-100309-68

Genes

tshz3b

Publication

Santos et al., 2010 - Phylogeny of the teashirt-related zinc finger (tshz) gene family and analysis of the developmental expression of tshz2 and tshz3b in the zebrafish

All Figures

Figures for Santos et al., 2010


Figure Caption

Fig. S4 tshz3b is expressed along the hindbrain, in the anterior spinal cord and in branchial arches 1-5 of 36hpf embryos.
In situ hybridization of 36hpf embryos using a tshz3b RNA probe. (A) Lateral view with dorsal up and anterior to the left. (1-9) 40μm transversal vibratome sections of the embryo in (A) at different AP levels of the hindbrain. First and last sections are represented in (A) as 1 and 9, respectively. tshz3b is expressed in medial and lateral regions of the medulla oblongata (4-6) in the ventral neural tube, and this expression fades towards posterior (7-9). (B) Dorso-lateral view with dorsal up and anterior to the left at the branchial arches (ba) level. tshz3b is expressed in branchial arches 1-5.

Figure Data

Expression / Labeling details
