Fig. 2

ID
ZDB-IMAGE-100302-23
Genes
Source
Figures for Drerup et al., 2010
Figure Caption

Fig. 2 lis1a is expressed in the peripheral and central nervous system of the developing zebrafish. (A and B) In situ hybridization with a lis1a specific probe illustrates a lack of expression in the zebrafish embryo at 14 hpf and 16 hpf. (C and G) At 24 hpf, there is expression of this transcript in the forebrain, midbrain and hindbrain. In addition, there is light expression in the trigeminal ganglion, a part of the peripheral nervous system (G, arrowhead). (D–F,H–J) Expression of lis1a continues in the developing zebrafish brain and peripheral nervous system into larval stages, 72 hpf through 120 hpf, when the larvae have begun to freely swim and feed. MHB-midbrain–hindbrain boundary. Arrowheads (G–J) indicate the trigeminal ganglion. C–F views are lateral with anterior to the left. A,B,G–J views are dorsal with anterior to the left. There is nonspecific probe trapping in the pharynx and swimbladder.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 10(1), Drerup, C.M., Wiora, H.M., and Morris, J.A., Characterization of the overlapping expression patterns of the zebrafish LIS1 orthologs, 75-85, Copyright (2010) with permission from Elsevier. Full text @ Gene Expr. Patterns
