Figure Caption
Fig. S3
Notch activity regulates v2aIN versus v2bIN identity in zebrafish.
Wild-type (A,D,G), mindbomb mutant (B,E,H), or Tg(hsp70:gal4;uas:NICD) (C,F,I) zebrafish embryos were analyzed by whole-mount in situ hybridization at 26 hours post-fertilization with probes marking v2a (scl and gata3) or v2b (vsx1/chox10) IN fate. Black arrowheads show v2IN, red arrowheads denote blood. Anterior, left, 10X magnification and 40X magnification of the boxed region as displayed in (A).
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Neuron
