ZFIN Image: Kitaguchi et al., 2009, Fig. S1


Figure Caption

Fig. S1 (A) Synthetic mRNA (250 pg) for C/ebp1-Nterminal-EGFP containing c/ebp1 MOs target sequences was injected into one blastomere of one- or two-cell stage embryos. Subsequently, morpholinos (c/ebp1 MO, 10 ng; c/ebp1 5mMO, 10 ng; c/ebp1 MO2, 2 ng) were injected into the yolk. The c/ebp1 5mMO is a 5 base mis-matched control morpholino for c/ebp1 MO. The expression of C/ebp1-Nterminal-EGFP at shield stage was effectively suppressed in c/ebp1 MO- and c/ebp1 MO2-injected embryos, but not in c/ebp1 5mMO-injected embryo. (B) lyz expression was inhibited in c/ebp1 MO- and c/ebp1 MO2-injected embryos, while c/ebp1 5mMO injection did not affect lyz expression.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Mechanisms of Development, 126(5-6), Kitaguchi, T., Kawakami, K., and Kawahara, A., Transcriptional regulation of a myeloid-lineage specific gene lysozyme C during zebrafish myelopoiesis, 314-323, Copyright (2009) with permission from Elsevier. Full text @ Mech. Dev.
