Figure Caption
Fig. S4 ISH analysis of hspa9 and yng/smarca4 mutants. Respective gene expressions were detected in mutants (upper panels) and wild type siblings (lower panels). 5–7 mutant larvae were used for each probe.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 325(1), Yoshinari, N., Ishida, T., Kudo, A., and Kawakami, A., Gene expression and functional analysis of zebrafish larval fin fold regeneration, 71-81, Copyright (2009) with permission from Elsevier. Full text @ Dev. Biol.
