Fig. 1

ID
ZDB-IMAGE-081219-41
Source
Figures for Siegfried et al., 2008
Figure Caption

Fig. 1 Zebrafish lacking germ cells make testes. H&E stainings of adult (7 month old) wild-type and germ line deficient testes. (A) Wild-type testis. The testis is organized in tubules surrounded by basement membrane, outlined in black (A′). Within the tubules, cysts of germ cells undergo spermatogenesis synchronously, outlined in blue (A′). Spermatozoa (sz) are released into the center, which connects to the efferent ducts. Sertoli cells (arrowheads and inset) are found within the tubules and Leydig cells (L) are in the interstitial spaces, colored purple (A′). (B) Germ line deficient testis. Testis tubules are formed, outlined in black (B′). Sertoli cells are lining the inside of the tubules (some marked by arrowheads and shown in inset). Leydig cells (L) are intertubular, colored purple (B′). Vasculature is also present in intertubular regions. sz, spermatozoa; st, spermatids; sg, spermatogonia. Scale bars are 10 μm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 324(2), Siegfried, K.R., and Nüsslein-Volhard, C., Germ line control of female sex determination in zebrafish, 277-287, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
