Figure Caption
Fig. 4 Recovery of myog expression upon initial down-regulation in six1a morphants. Flat mount embryos after WISH for myog. Wild-type embryos (A, C, E) and UM morphants (B, D, F). Arrowheads mark myog expression in fast muscle precursors. Note that the myog expression is nearly absent along the entire posterior border in all somites in morphants at 9 s, increased at 10 s and recovered at 13 s. Also note the delay of recovery in the most posterior somites at 13 s (brackets). Scale bar, 100 μm.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 323(2), Bessarab, D.A., Chong, S.W., Srinivas, B.P., and Korzh, V., Six1a is required for the onset of fast muscle differentiation in zebrafish, 216-228, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
