Fig. 8

ID
ZDB-IMAGE-080403-321
Genes
Publication
Thisse et al., 2008 - Expression from: Unexpected Novel Relational Links Uncovered by Extensive Developmental Profiling of Nuclear Receptor Expression
All Figures
Figures for Thisse et al., 2008[dq017626]
Figure Caption

Fig. 8 Expressed in retina (more labelling in proliferative zone, expression decreasing in more differentiated cells), tectum, cerebellum and lateral line neuromasts
Please note that in 5 day old embryos some structures are not accessible to the probe (such as notochord, most of the trunk and tail). Therefore the description of the expression pattern is only partial.

Orientation
Preparation Image Form View Direction
whole-mount still side view anterior to left
Figure Data
