Fig. 6

ID
ZDB-IMAGE-070802-52
Source
Figures for Gansner et al., 2007
Figure Caption

Fig. 6 Partial knockdown of loxl5b sensitizes embryos to notochord distortion in the presence of suboptimal copper nutrition (A–D) or disruption of col2a1 (E, F). Wild-type embryos were injected with 5 ng of control morpholino (A, C) or loxl5b morpholino (B, D), and incubated with (C, D) or without (A, B) 2 μM neocuproine starting at 3 hpf. Embryos injected with loxl5b morpholino develop notochord distortion (arrowhead) in the context of diminished copper availability (D). Embryos injected with 7.4 ng of col2a1 morpholino (E) are sensitized to develop notochord distortion (arrowhead) upon co-injection of 5 ng of loxl5b morpholino (F), demonstrating a genetic interaction between col2a1 and loxl5b. Photographs were obtained at 30 hpf (A–D) and 24 hpf (E, F).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 307(2), Gansner, J.M., Mendelsohn, B.A., Hultman, K.A., Johnson, S.L., and Gitlin, J.D., Essential role of lysyl oxidases in notochord development, 202-213, Copyright (2007) with permission from Elsevier. Full text @ Dev. Biol.
