Fig. 2

ID
ZDB-IMAGE-070331-4
Source
Figures for Rich et al., 2007
Figure Caption

Fig. 2 Cells with Kit-like immunoreactivity form a dense network in the myenteric plexus region, and a second network close to the circular smooth muscle-submucosal border. High magnification of Kit-positive cells reveals individual stellate-shaped cells (white) in a full thickness stack (A). Circular and longitudinal muscle layers of the adult GI tract are clearly observed in H&E stained transverse sections (B). Kit-positive cells are found in the myenteric plexus region, and a thin layer of Kit-positive cells is located near the circular smooth muscle-submucosal border (C). A single layer of Kit-positive cells was observed in the tunica muscularis of transverse sections of zebrafish larvae (white arrow) (D). Scale bars = 20 μm.

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
