ZFIN Image: Nambiar et al., 2004, Fig. 4


Figure Caption

Fig. 4 col mutants display an expansion of non-neural ectoderm and a reduction in neural tissue during late gastrulation. (A,B) At 80% epiboly (8.5 hpf; A; lateral view), gata2 is expressed by non-neural ectoderm in wild-type embryos. The domain of gata2 expression is expanded dorsally and anteriorly in col mutants (B). Arrowheads in A and B denote limits of the gata2 expression domains. (C,D) At 75% epiboly (8 hpf; C; lateral view), otx2 is expressed by the forebrain and midbrain anlage of the neuroectoderm in wild-type embryos (C). In col mutants (D), otx2 expression is reduced and the anterior border of the expression domain (arrowheads) does not reach the animal pole.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 267(1), Nambiar, R.M., and Henion, P.D., Sequential antagonism of early and late Wnt-signaling by zebrafish colgate promotes dorsal and anterior fates, 165-80, Copyright (2004) with permission from Elsevier. Full text @ Dev. Biol.
