Fig. 1
- ID
- ZDB-IMAGE-050812-8
- Publication
- Sadler et al., 2005 - A genetic screen in zebrafish identifies the mutants vps18, nf2 and foie gras as models of liver disease
- All Figures
- Figures for Sadler et al., 2005
|
Figure Caption
Fig. 1 Seven mutants develop hepatomegaly by day 5 of development. (A) CY3-SA specifically labels the liver and gut in day 5 wild-type embryos. Scale bar: 100 µm. (B) Live images (left) and CY3-SA-labeled livers of wild-type and mutant embryos. The liver is outlined in red. The gut is indicated in each embryo, except fgr, which has an underdeveloped gut that does not label with CY3-SA. Scale bars: 50 µm.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
