Figure Caption
Fig. 3
Morphology, histopathological examination and vascular structure in ethanol-treated and untreated larvae. (A-C) Morphological characteristics of ethanol-treated and untreated larvae at 6dpf. (D-I) H&E staining of transverse sections at site of abdomen in untreated and ethanol-treated larvae. Boxed areas in D,F,H magnified in E,G,I. (J,L,N) Reconstructed images of vascular structure in untreated and ethanol-treated larvae by confocal imaging. (K,M,O) Tomography of vascular structure in control and alcohol-treated larvae by confocal imaging. Asterisk in N,O indicates destruction in dorsal aorta.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Biol. Open
