Fig. 4

ID
ZDB-IMAGE-130802-47
Genes
Source
Figures for Campbell et al., 2013
Figure Caption

Fig. 4 kif5 expression during early zebrafish development. Maternal expression of kif5s was apparent in cleavage stage for kif5Ba, kif5Bb, and kif5C, but not kif5Aa (A–D). Expression of kif5s at sphere (E–H), shield (I–L), bud (M-P), 15 somite (Q–T), and 19 somite (U–X) stages. Arrowheads indicate trigeminal ganglion and arrows indicate otic placode. All images are lateral views. For A–L, An = Animal pole, Vg = vegetal pole. For M–X, A = Anterior, P = Posterior, V = Ventral, D = Dorsal. Dashed line represents border between notochord and spinal cord. fb, forebrain; mb, midbrain; hb, hindbrain; ey, eye.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 13(7), Campbell, P.D., and Marlow, F.L., Temporal and tissue specific gene expression patterns of the zebrafish kinesin-1 heavy chain family, kif5s, during development, 271-279, Copyright (2013) with permission from Elsevier. Full text @ Gene Expr. Patterns
