Fig. S6 Fli1 expression in the PLM is independent of Cloche at an early stage.
(A,B) Whole mount in situ hybridisation showing Fli1 expression in wild type (A) and Cloche (B) embryos at 6s. Note that PLM expression of Fli1 is retained in Cloche (black arrows), whereas ALM expression is absent (red arrows); (C,D) Erg expression in wild type and Clo embryos; (E,F) Gata2 expression in wild type and Clo embryos; (G,H) Scl expression in wild type and Clo embryos; (I,J) Etsrp expression in wt and Clo embryos. Note that both ALM and PLM expression of Erg (D, red arrows), Scl (H, red arrows) and Etsrp (J, red arrows), and PLM expression of Gata2 (F, red arrows) are absent in Clo embryos.
