ZFIN Figure: Carmona-Aldana et al., 2018, Fig. 4

ZFIN ID: ZDB-FIG-190328-34

ZFIN ID: ZDB-FIG-190328-34

Carmona-Aldana et al., 2018 - CTCF knockout reveals an essential role for this protein during the zebrafish development. Mechanisms of Development 154:51-59 Full text @ Mech. Dev.

ADDITIONAL FIGURES

PHENOTYPE:

Fish:	WT + MO3-ctcf WT + MO4-ctcf
Knockdown Reagents:	MO3-ctcf MO4-ctcf
Observed In:	brain segmentation eye forebrain hindbrain midbrain notochord post-vent region somite whole organism
Stage:	Prim-5

Fig. 4 Phenotype of the CTCF morphants. 1-cell to 2-cell embryos were injected with mo-aug or mo-sp. A range of phenotypes was found at 24 hpf, from wild type, mild and severe phenotypes. Different structures were affected: a. Forebrain, b. Midbrain, c. Hindbrain, d. Eye, e. Notochord f. Somites. The percentages and the median of embryos with a mild or severe phenotype are shown in the graph. The statistical difference is noted with an asterisk (n = 4 assays, p = 0.006 for mo-aug; n = 9 assays, p = 0.2609 for mo-sp; one-tailed unpaired t-tests).

Gene Expression Details No data available

Antibody Labeling Details No data available

Phenotype Details

Fish	Conditions	Stage	Phenotype
WT + MO3-ctcf	standard conditions	Prim-5	brain segmentation decreased process quality, abnormal
		Prim-5	eye hypoplastic, abnormal
		Prim-5	forebrain morphology, abnormal
		Prim-5	hindbrain morphology, abnormal
		Prim-5	midbrain morphology, abnormal
		Prim-5	notochord morphology, abnormal
		Prim-5	post-vent region decreased size, abnormal
		Prim-5	somite morphology, abnormal
		Prim-5	whole organism decreased length, abnormal
WT + MO4-ctcf	standard conditions	Prim-5	brain segmentation decreased process quality, abnormal
		Prim-5	eye hypoplastic, abnormal
		Prim-5	forebrain morphology, abnormal
		Prim-5	hindbrain morphology, abnormal
		Prim-5	midbrain morphology, abnormal
		Prim-5	notochord morphology, abnormal
		Prim-5	somite morphology, abnormal
