ZFIN ID: ZDB-FIG-171101-29
Astone et al., 2015 - A GFP-Tagged Gross Deletion on Chromosome 1 Causes Malignant Peripheral Nerve Sheath Tumors and Carcinomas in Zebrafish. PLoS One   10:e0145178 Full text @ PLoS One
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Anatomical Terms:
Stage: Prim-5
PHENOTYPE:
Fish:
Observed In:
Stage Range: Prim-5 to Protruding-mouth

Fig. 1

Phenotype of the ia2 mutant at 24 hpf.

The homozygous mutant (C) displays a strongly delayed development and compromised phenotype, while the heterozygote (B) appears indistinguishable from the wild-type (A). The green fluorescence relative to the -8.5nkx2.2a:GFP transgene is present in heterozygous and homozygous ia2 mutant fish, being the GFP gene co-inherited with the ia2 mutant allele. This allows the early and immediate screening of the three genotypes.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
GFP unm_ia2ia2Tg/+; unm_ia2Df(Chr01:timm10,rtn4rl2a,p2rx3b,pkd2,slc27a1b)ia2a/+ standard conditions Prim-5 head IFL
Prim-5 pancreatic bud IFL
Prim-5 trunk IFL
unm_ia2ia2Tg/ia2Tg; unm_ia2Df(Chr01:timm10,rtn4rl2a,p2rx3b,pkd2,slc27a1b)ia2a/ia2a standard conditions Prim-5 head IFL
Prim-5 pancreatic bud IFL
Prim-5 trunk IFL
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
unm_ia2ia2Tg/ia2Tg; unm_ia2Df(Chr01:timm10,rtn4rl2a,p2rx3b,pkd2,slc27a1b)ia2a/ia2a standard conditions Prim-5 embryo development arrested, abnormal
Prim-5 embryo development delayed, abnormal
Protruding-mouth whole organism decreased life span, abnormal
