ZFIN ID: ZDB-FIG-160726-18
Housley et al., 2016 - Cavin4b/Murcb Is Required for Skeletal Muscle Development and Function in Zebrafish. PLoS Genetics   12:e1006099 Full text @ PLoS Genet.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Antibodies:
Fish:
Anatomical Terms:
Stage: Days 45-89

Fig. S5

Immunofluorescence localization of Cav3 and Murc in adult skeletal muscle.

Confocal micrographs of transverse sections prepared from 10 wpf murcbs983/+ zebrafish and stained with anti-Murc (red) and anti-Cav3 (green). Merged views are shown on the right and below.

Gene Expression DetailsNo data available
Antibody Labeling Details
Antibody Assay Fish Conditions Stage Qualifier Anatomy
Ab1-cav3 IHC WT standard conditions Days 45-89 skeletal muscle cell cytoplasm
IHC Days 45-89 Not Detected skeletal muscle cell sarcolemma
Ab1-murc IHC WT standard conditions Days 45-89 Not Detected skeletal muscle cell cytoplasm
IHC Days 45-89 skeletal muscle cell sarcolemma
Phenotype Details No data available
