ZFIN ID: ZDB-FIG-110121-14
Choudhry et al., 2011 - Alcama mediates Edn1 signaling during zebrafish cartilage morphogenesis. Developmental Biology   349(2):483-493 Full text @ Dev. Biol.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Antibody:
Fish:
Anatomical Terms:
Stage: Prim-15

Fig. S2 alcama and nadl1.1 ISH in edn1-/- mutants. (A, B) 30 hpf WT larvae showing expression of alcama and ednrb1 respectively. (C, D) alcama ISH showing expression in pharyngeal pouches of WT and edn1-/- larvae at 30 hpf. (E, F) 30 hpf larvae stained with Alcama antibody (Fast Red) and nadl1.1 RNA (Fluorescein). nadl1.1 expression in the NC is unchanged while Alcama is down-regulated in edn1-/- mutants (F). Arrows point to alcama expression in the pharyngeal pouches. Scale bars: 50 μm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
alcama zn-5 WT standard conditions Prim-15 pharyngeal pouch 2 IHC
Prim-15 pharyngeal pouch 2 ISH
Prim-15 pharyngeal pouch 3 ISH
zn-5 Prim-15 pharyngeal pouch 3 IHC
zn-5 Prim-15 pharyngeal pouch 4 IHC
Prim-15 pharyngeal pouch 4 ISH
zn-5 edn1tf216b/tf216b standard conditions Prim-15 pharyngeal pouch IHC
ednrba WT standard conditions Prim-15 head endoderm ISH
Prim-15 head neural crest ISH
l1camb WT standard conditions Prim-15 pharyngeal arch OTHR
edn1tf216b/tf216b standard conditions Prim-15 pharyngeal arch OTHR
Antibody Labeling Details No data available
Phenotype Details No data available
Acknowledgments:
ZFIN wishes to thank the journal Developmental Biology for permission to reproduce figures from this article. Please note that this material may be protected by copyright.

Reprinted from Developmental Biology, 349(2), Choudhry, P., Joshi, D., Funke, B., and Trede, N., Alcama mediates Edn1 signaling during zebrafish cartilage morphogenesis, 483-493, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
