Fig. 3

Differential requirement of myeloid-expressed transcription factor on the expression of c/ebp1, pu.1 and runx1. Whole-mount in situ hybridization with probes shown at bottom right of each panel. Injected morpholinos are indicated at top right. All embryos are around 24 hpf and lateral view; anterior is left. (A–D) lyz expression was inhibited in pu.1 MO-, runx1 MO- and c/ebp1 MO-injected embryos. (E–G) The expression of c/ebp1 in myeloid cells was suppressed in pu.1 morphants, but not in runx1 morphants. (H–J) The runx1 expression in myeloid cells (red arrowheads; H and J), but not in the ICM and Rohon-beard cells, was inhibited in pu.1 morphants, while injection of c/ebp1 MO did not affect runx1 expression. (K–M) pu.1 expression in myeloid cells was comparably detected in uninjected-, runx1 MO-injected and c/ebp1 MO-injected embryos.

Expression Data
Genes:
Fish:
Knockdown Reagents:
Anatomical Terms:
Stage: Prim-5

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Mechanisms of Development, 126(5-6), Kitaguchi, T., Kawakami, K., and Kawahara, A., Transcriptional regulation of a myeloid-lineage specific gene lysozyme C during zebrafish myelopoiesis, 314-323, Copyright (2009) with permission from Elsevier. Full text @ Mech. Dev.
