Fig. 3

Expression of steif in the mutant restores myofibrils. (A) uninjected wild-type, (B) steif mutant injected with the BAC clone encoding the steif/unc-45b gene fused with CFP, (C) uninjected steif mutant. The color code on the inserted bar represents the intensity of birefringence covering a five fold range from red (high) to blue (low). (D) F59 staining of BAC-injected steif embryos showing rescue of single fibrils (arrowhead). (E) magnification of panel F. Muscle cells expressing Steif-CFP show normal striation (A-band, arrow head, vertical lines, Z-lines). (F–I) Steif-GFP plasmid injection into steif mutant embryos led to recovery of birefringence and rescue of myofibril organization (F, GFP fluorescence; G, birefringence; H, merge of panels F and G). (I) α-actinin staining showing a rescued fibril in steif mutant embryos (arrow indicates Z-line). Scale bars: 150 μm (A–C); 12 μm (D, F–H); 2 μm (E), 5 μm (I). (A–I) 3-day-old embryos.

Expression Data

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Observed In:
Stage: Protruding-mouth

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 308(1), Etard, C., Behra, M., Fischer, N., Hutcheson, D., Geisler, R., and Strähle, U., The UCS factor Steif/Unc-45b interacts with the heat shock protein Hsp90a during myofibrillogenesis, 133-143, Copyright (2007) with permission from Elsevier. Full text @ Dev. Biol.
