Fig. 4

Expression domain of ff1a in slow muscle is modulated by components of the Hedgehog signaling pathway. (A–F) Lateral view with the anterior to the left. (A) The expression domain of ff1a in the somites at 15 hpf. (B) Misexpression of mouse Shh RNA led to the expansion of the expression domain of ff1a. (C) ff1a expression is down-regulated in the trunk somites at 24 hpf, (D) ff1a RNA is retained in Shh overexpressed embryos. (E) Weak ff1a expression could be seen in control embryo at 20 hpf, (F) whereas in forskolin-treated embryos, ff1a expression is abolished in the somites. (G–J) Cross-sections of the embryos in panels (A, B) are shown in panels (G, H), respectively. Expression domain of ff1a in the somites at 18 hpf (I) was expanded in embryos where PKI was overexpressed (J).

Expression Data
Gene:
Fish:
Condition:
Anatomical Term:
Stage: 20-25 somites

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 286(2), Sheela, S.G., Lee, W.C., Lin, W.W., and Chung, B.C., Zebrafish ftz-f1a (nuclear receptor 5a2) functions in skeletal muscle organization, 377-390, Copyright (2005) with permission from Elsevier. Full text @ Dev. Biol.
